BT-B258 is a portable multifunctional GNSS receiver, a new generation of measurement engine, supporting tilt measurement, built-in 4G Modem,Radio, Bluetooth and WiFi. It adopts a new appearance design, magnesium alloy structure and Linux operating system. It is an extremely lightweight, fully functional and portable geodesic GNSS receiver.

Linux intelligent system

Linux+Qualcomm MDM9628 Cortex-A7, the intelligent system platform, brings users efficient computing and unlimited expansion of product functions.

Multi constellation

Full system full-frequency point GNSS receiver

The host integrates high-precision positioning module, supporting BDS B1I, B2I, B3I, B1C, B2a, B2b, GPS L1C/A, LIC, L2P (Y), L2C, L5, GLONASSE1, E5a, E5b, E6, Galileo E1, E5a, E5b, E6*, SBAS L1, QZSS L1, L2, L5, L6*

Tilt measurement

On BT-B258 is available the IMU technology. Fast initialization, up to 60° inclination.

4G Modem

BT-B258 has an internal 4G modem that operates with more Cellular network signals, a fast internet connection is guaranteed.

Combined antenna

The new four in one antenna integrates GNSS, WiFi, Bluetooth and 4G, with smaller volume and better signal.

Long endurance

Built in high-capacity lithium battery ensures continuous working time of more than 18 hours under normal operation.

Characteristic

• Linux+QualcommMDM9628 Cortex-A7 intelligent system.
• BDS,GPS,GLONASS,Galileo,QZSSand SBAS.
• Centimeter level positioning.
• Support tilt measurement, and meet the positioning accuracy of less than 2cm within the tilt range of 60°.
• Support 4G, Radio,Bluetooth and WiFi, and work more flexibly.
• Built in high-capacity lithium battery, ultra long life.
• Industrial design, solid magnesium alloy shell, in line with IP67 design requirements, safe and reliable.
• With 1408 super channels
